Generation of Toyota Vitz

Generation

Toyota Vitz III Generation

Produced from 2010 to 2014

Makes » Toyota » Toyota Vitz » Toyota Vitz III Generation

Informations about

Still in production

Trim Levels/Versions

13
YearModel NameFuelBodyWheelDrivePr.FromtoSpeedQOD
YearModel NameFuelBodyWheelDrivePr.FromtoSpeedQOD
2010 2010 Toyota Vitz 1.3U 4WD DBA-NSP135-AHXEK Petrol HatchbackUNK - 1
F
2010 2010 Toyota Vitz 1.5 RS DBA-NCP131-AHMVK Petrol HatchbackUNK - 1
F
2010 2010 Toyota Vitz 1.5 RS CVT DBA-NCP131-AHXVK Petrol HatchbackUNK - 1
F
2010 2010 Toyota Vitz 1.5U DBA-NCP131-AHXEK Petrol HatchbackUNK - 1
F
2010 2010 Toyota Vitz 1.3U DBA-NSP130-AHXEK Petrol HatchbackUNK - 1
F
2010 2010 Toyota Vitz 1.3 Jewela 4WD DBA-NSP135-AHXGK Petrol HatchbackUNK - 1
F
2010 2010 Toyota Vitz 1.3 Jewela DBA-NSP130-AHXGK Petrol HatchbackUNK - 1
F
2010 2010 Toyota Vitz 1.3F Smart Stop DBA-NSP130-AHXNK (I) Petrol HatchbackUNK - 1
F
2010 2010 Toyota Vitz 1.3F 4WD DBA-NSP135-AHXNK Petrol HatchbackUNK - 1
F
2010 2010 Toyota Vitz 1.3F DBA-NSP130-AHXNK Petrol HatchbackUNK - 1
F
2010 2010 Toyota Vitz 1.0 Jewela DBA-KSP130-AHXGK Petrol HatchbackUNK - 1
F
2010 2010 Toyota Vitz 1.0F DBA-KSP130-AHXNK Petrol HatchbackUNK - 1
F
2013 2013 Toyota Vitz GRMN Turbo Petrol HatchbackUNK - 1
F

Engines

4
» Petrol Engines
Id.Engine996 cc1329 cc1496 cc1497 cc
Kind of EngineNaturally aspiratedNaturally aspiratedTurbochargedNaturally aspirated
Identificative engine1kr-fe 1nr-fe 1nz-fe turbo 1nz-fe
Cylinders ConfigurationStraight/Inline EngineStraight/Inline EngineStraight/Inline EngineStraight/Inline Engine
Displacement996 cc1329 cc1496 cc1497 cc
Cylinders number3 4 4 4
FuelPetrolPetrolPetrolPetrol
Electric engine - kind
Battery kind
Peak Power (hp)
Peak Power (kW)
Battery power
Operating Voltage
Battery: Operating Temperature
Battery: System Voltage
Battery: Cell Configuration
Battery: 0-80% Charge time
Torque92 N-m121 N-m206 N-m138 N-m
Torque @ r.p.m. 3600 rpm 4000 rpm 4000 rpm 4400 rpm
Cylinders angle
Maximum Power (HP)68 hp94 hp150 hp107 hp
Power (PS)69 ps95 ps152 ps108 ps
Power kW51 kW70 kW112 kW80 kW
Power @ rounds per minute6000 rpm6000 rpm6000 rpm6000 rpm
Bore71 mm72.5 mm75 mm75 mm
Stroke83.9 mm80.5 mm84.7 mm84.7 mm
Valve TrainDouble overhead camshaft DOHCDouble overhead camshaft DOHCDouble overhead camshaft DOHCDouble overhead camshaft DOHC
Compression Ratio10.5:1 11.5:1 10.5:1
Engine block material
Cylinder head material
Fuel Systemefiefiefiefi
CoolantWaterWaterWaterWater
Engine Data accuracy
D
Vitz 1.0 Jewela
Vitz 1.0F
Vitz 1.3U 4WD
Vitz 1.3U
Vitz 1.3 Jewela 4WD
Vitz 1.3 Jewela
Vitz 1.3F Smart Stop
Vitz 1.3F 4WD
Vitz 1.3F
Vitz GRMN Turbo
Vitz 1.5 RS
Vitz 1.5 RS CVT
Vitz 1.5U

Car body variants

1 HAT
Variants#HAT
#HAT
#HAT
Body styleHatchbackHatchbackHatchback
no.Doors
Wheelbase2510 mm2510 mm2510 mm
Lenght3885 mm3930 mm3945 mm
Width1695 mm1695 mm1695 mm
Height1500 mm1500 mm1490 mm
Curb Weight
Wheel Drive
Engine LocationFrontFrontFront
Chassis
Seating capacity (number)
Track Tread (front)1485 mm1460 mm
Track Tread (rear)1470 mm1445 mm
Luggage capacity (min)
Luggage capacity (max)
Weight distribution (FRONT)
Engine AlignmentTransverseTransverseTransverse
Drag Coefficient
Equipment
Vitz 1.3U 4WD
Vitz 1.5U
Vitz 1.3U
Vitz 1.3 Jewela 4WD
Vitz 1.3 Jewela
Vitz 1.3F Smart Stop
Vitz 1.3F 4WD
Vitz 1.3F
Vitz 1.0 Jewela
Vitz 1.0F
Vitz 1.5 RS
Vitz 1.5 RS CVT
Vitz GRMN Turbo
