TOYOTA MR2 MKI (W10)

Generation of TOYOTA MR2
Produced from 1984 to 1989


Upload an image
HOME » Toyota » TOYOTA MR2 » TOYOTA MR2 MKI (W10)

Informations about (**)

End of production

Trim Levels/Versions 11

YearModel NameFuelBodyWheelDrivePr.FromtoSpeedQOD
YearModel NameFuelBodyWheelDrivePr.FromtoSpeedQOD
1984 1984 Toyota MR2 AW11 Petrol CoupéRWD 197 km/h 1
E
1984 1984 Toyota MR2 1500S AW11 E-AW10-WCMSS Petrol CoupéRWD 171 km/h 1
E
1984 1984 Toyota MR2 1500S Automatic AW11 E-AW10-WCPSS Petrol CoupéRWD - 1
E
1984 1984 Toyota MR2 1600G Limited AW11 E-AW11-WCMQF Petrol CoupéRWD - 1
E
1984 1984 Toyota MR2 1600G Limited Automatic AW11 E-AW11-WCPQF Petrol CoupéRWD - 1
E
1985 1985 Toyota MR2 1500S AW11 E-AW10-WCMSS Petrol CoupéRWD - 1
E
1985 1985 Toyota MR2 1500S Automatic AW11 E-AW10-WCPSS Petrol CoupéRWD - 1
E
1986 1986 Toyota MR2 Supercharged 1600G Limited AW11 E-AW11-WCMQR Petrol CoupéRWD - 1
E
1986 1986 Toyota MR2 Supercharged 1600G Limited Automatic AW11 E-AW11-WCPQR Petrol CoupéRWD - 1
E
1987 1987 Toyota MR2 1600G Limited Automatic AW11 E-AW11-WCPQR Petrol CoupéRWD - 1
E
1987 1987 Toyota MR2 1600G Limited AW11 E-AW11-WCMQR Petrol CoupéRWD - 1
E

Engines (11)

» Petrol Engines
Id.Engine1453 cc1453 cc1453 cc1453 cc1587 cc1587 cc1587 cc1587 cc1587 cc1587 cc1587 cc
Kind of EngineNaturally aspiratedNaturally aspiratedNaturally aspiratedNaturally aspiratedNaturally aspiratedNaturally aspiratedNaturally aspiratedNaturally aspiratedNaturally aspiratedSuperchargedSupercharged
Identificative engine3a-lu 3a-lu 3a-lu 3a-lu 4a-gelu 4a-gelu 4a-gelu 4a-gelu 4a-gze 4a-gze
Cylinders ConfigurationStraight/Inline EngineStraight/Inline EngineStraight/Inline EngineStraight/Inline EngineStraight/Inline EngineStraight/Inline EngineStraight/Inline EngineStraight/Inline EngineStraight/Inline EngineStraight/Inline EngineStraight/Inline Engine
Displacement1453 cc1453 cc1453 cc1453 cc1587 cc1587 cc1587 cc1587 cc1587 cc1587 cc1587 cc
Cylinders number4 4 4 4 4 4 4 4 4 4 4
FuelPetrolPetrolPetrolPetrolPetrolPetrolPetrolPetrolPetrolPetrolPetrol
Electric engine - kind
Battery kind
Peak Power (hp)
Peak Power (kW)
Battery power
Operating Voltage
Battery: Operating Temperature
Battery: System Voltage
Battery: Cell Configuration
Battery: 0-80% Charge time
Torque118 N-m118 N-m118 N-m118 N-m142 N-m142 N-m142 N-m149 N-m149 N-m186 N-m186 N-m
Torque @ r.p.m. 3600 rpm 3600 rpm 3600 rpm 3600 rpm 5200 rpm 5200 rpm 5000 rpm 5200 rpm 5200 rpm 4400 rpm 4400 rpm
Cylinders angle
Maximum Power (HP)82 hp82 hp82 hp82 hp118 hp118 hp122 hp128 hp128 hp143 hp143 hp
Power (PS)83 ps83 ps83 ps83 ps120 ps120 ps124 ps130 ps130 ps145 ps145 ps
Power kW61 kW61 kW61 kW61 kW88 kW88 kW91 kW95 kW95 kW107 kW107 kW
Power @ rounds per minute5600 rpm5600 rpm5600 rpm5600 rpm6600 rpm6600 rpm6600 rpm6600 rpm6600 rpm6400 rpm6400 rpm
Bore77.5 mm77.5 mm77.5 mm77.5 mm81 mm81 mm81 mm81 mm81 mm81 mm81 mm
Stroke77 mm77 mm77 mm77 mm77 mm77 mm77 mm77 mm77 mm77 mm77 mm
Valve TrainSingle overhead camshaft SOHCSingle overhead camshaft SOHCSingle overhead camshaft SOHCSingle overhead camshaft SOHCDouble overhead camshaft DOHCDouble overhead camshaft DOHCDouble overhead camshaft DOHCDouble overhead camshaft DOHCDouble overhead camshaft DOHCDouble overhead camshaft DOHCDouble overhead camshaft DOHC
Compression Ratio9.3:1 9.3:1 9.3:1 9.3:1 9.4:1 9.4:1 10:1 9.4:1 9.4:1 8:1 8:1
Engine block material
Cylinder head material
Fuel System1 ai carb1 ai carb1 ai carb1 ai carbefiefitccs fuel inj.efiefiefiefi
CoolantWaterWaterWaterWaterWaterWaterWaterWaterWaterWaterWater
Engine Data accuracy
MR2 1500S
MR2 1500S Automatic
MR2 1500S
MR2 1500S Automatic
MR2 1600G Limited
MR2 1600G Limited Automatic
MR2
MR2 1600G Limited
MR2 1600G Limited Automatic
MR2 Supercharged 1600G Limited
MR2 Supercharged 1600G Limited Automatic

Car body variants (1)

COU
Variants#COU
#COU
#COU
Body styleCoupéCoupéCoupé
no.Doors
Wheelbase2320 mm2320 mm2320 mm
Lenght3925 mm3925 mm3950 mm
Width1665 mm1665 mm1665 mm
Height1250 mm1250 mm1250 mm
Curb Weight
Wheel Drive
Engine LocationMiddleMiddleMiddle
Chassis
Seating capacity (number)
Track Tread (front)1440 mm1440 mm1440 mm
Track Tread (rear)1440 mm1445 mm1440 mm
Luggage capacity (min)
Luggage capacity (max)
Weight distribution (FRONT)
Engine AlignmentTransverseTransverseTransverse
Drag Coefficient
Equipment
MR2
MR2 1500S
MR2 1500S Automatic
MR2 1600G Limited
MR2 1600G Limited Automatic
MR2 1500S
MR2 1500S Automatic
MR2 Supercharged 1600G Limited
MR2 Supercharged 1600G Limited Automatic
MR2 1600G Limited Automatic
MR2 1600G Limited
