Mercedes-Benz A-Class W169 (2004)

Generation of Mercedes-Benz A-Class
Produced from 2004 to 2008


Upload an image
HOME » Mercedes-Benz » Mercedes-Benz A-Class » Mercedes-Benz A-Class W169 (2004)

Informations about (**)

End of production

Trim Levels/Versions 14

YearModel NameFuelBodyWheelDrivePr.FromtoSpeedQOD
YearModel NameFuelBodyWheelDrivePr.FromtoSpeedQOD
2004 2004 Mercedes-Benz A 150 W 169 Petrol Hatchback - 1
E
2004 2004 Mercedes-Benz A 160 CDI W 169 Diesel Hatchback - 1
E
2004 2004 Mercedes-Benz A 170 W 169 Petrol Hatchback - 1
E
2004 2004 Mercedes-Benz A 180 CDI W 169 Diesel Hatchback - 1
E
2004 2004 Mercedes-Benz A 200 W 169 Petrol Hatchback - 1
E
2004 2004 Mercedes-Benz A 200 CDI W 169 Diesel HatchbackUNK 201 km/h 1
E
2004 2004 Mercedes-Benz A 200 Turbo W 169 Petrol Hatchback - 1
E
2006 Mercedes-Benz A 150 Automatic W 169 Petrol Hatchback - 1
E
2006 Mercedes-Benz A 160 CDI Automatic W 169 Diesel Hatchback - 1
E
2006 Mercedes-Benz A 170 Automatic W 169 Petrol Hatchback - 1
E
2006 Mercedes-Benz A 180 CDI Automatic W 169 Diesel Hatchback - 1
E
2006 Mercedes-Benz A 200 Automatic W 169 Petrol Hatchback - 1
E
2006 Mercedes-Benz A 200 CDI Automatic W 169 Diesel Hatchback - 1
E
2006 Mercedes-Benz A 200 Turbo Automatic W 169 Petrol Hatchback - 1
E

Engines (13)

» Diesel Engines
Id.Engine1991 cc1991 cc1991 cc1991 cc1991 cc
Kind of EngineTurbochargedTurbochargedTurbochargedTurbochargedTurbocharged
Identificative engine
Cylinders ConfigurationStraight/Inline EngineStraight/Inline EngineStraight/Inline EngineStraight/Inline EngineStraight/Inline Engine
Displacement1991 cc1991 cc1991 cc1991 cc1991 cc
Cylinders number4 4 4 4 4
FuelDieselDieselDieselDieselDiesel
Electric engine - kind
Battery kind
Peak Power (hp)
Peak Power (kW)
Battery power
Operating Voltage
Battery: Operating Temperature
Battery: System Voltage
Battery: Cell Configuration
Battery: 0-80% Charge time
Torque180 N-m180 N-m250 N-m250 N-m300 N-m
Torque @ r.p.m. 1400-2600 rpm 1400-2600 rpm 1600-2600 rpm 1600-2600 rpm 1600-2600 rpm
Cylinders angle
Maximum Power (HP)81 hp81 hp107 hp107 hp138 hp
Power (PS)82 ps82 ps108 ps108 ps140 ps
Power kW60 kW60 kW80 kW80 kW103 kW
Power @ rounds per minute4200 rpm4200 rpm4200 rpm4200 rpm4200 rpm
Bore83 mm83 mm83 mm83 mm83 mm
Stroke92 mm92 mm92 mm92 mm92 mm
Valve TrainDouble overhead camshaft DOHCDouble overhead camshaft DOHCDouble overhead camshaft DOHCDouble overhead camshaft DOHCDouble overhead camshaft DOHC
Compression Ratio18:1 18:1 18:1 18:1 18:1
Engine block material
Cylinder head material
Fuel Systemcommon rail direct diesel injectioncommon rail direct diesel injectioncommon rail direct diesel injectioncommon rail direct diesel injectioncommon rail direct diesel injection
CoolantWaterWaterWaterWaterWater
Engine Data accuracy
D
A 160 CDI
A 160 CDI Automatic
A 180 CDI
A 180 CDI Automatic
A 200 CDI
A 200 CDI Automatic
» Petrol Engines
Id.Engine1498 cc1498 cc1699 cc1699 cc2034 cc2034 cc2034 cc2034 cc
Kind of EngineNaturally aspiratedNaturally aspiratedNaturally aspiratedNaturally aspiratedNaturally aspiratedNaturally aspiratedTurbochargedTurbocharged
Identificative engine
Cylinders ConfigurationStraight/Inline EngineStraight/Inline EngineStraight/Inline EngineStraight/Inline EngineStraight/Inline EngineStraight/Inline EngineStraight/Inline EngineStraight/Inline Engine
Displacement1498 cc1498 cc1699 cc1699 cc2034 cc2034 cc2034 cc2034 cc
Cylinders number4 4 4 4 4 4 4 4
FuelPetrolPetrolPetrolPetrolPetrolPetrolPetrolPetrol
Electric engine - kind
Battery kind
Peak Power (hp)
Peak Power (kW)
Battery power
Operating Voltage
Battery: Operating Temperature
Battery: System Voltage
Battery: Cell Configuration
Battery: 0-80% Charge time
Torque140 N-m140 N-m155 N-m155 N-m185 N-m185 N-m280 N-m280 N-m
Torque @ r.p.m. 1600-2600 rpm 1600-2600 rpm 3500 rpm 3500 rpm 3500-4000 rpm 3500-4000 rpm 1800-4850 rpm 1800-4850 rpm
Cylinders angle
Maximum Power (HP)94 hp94 hp114 hp114 hp134 hp134 hp190 hp190 hp
Power (PS)95 ps95 ps116 ps116 ps136 ps136 ps193 ps193 ps
Power kW70 kW70 kW85 kW85 kW100 kW100 kW142 kW142 kW
Power @ rounds per minute5200 rpm5200 rpm5500 rpm5500 rpm5750 rpm5750 rpm5000 rpm5000 rpm
Bore83 mm83 mm83 mm83 mm83 mm83 mm83 mm83 mm
Stroke69.2 mm69.2 mm78.5 mm78.5 mm94 mm94 mm94 mm94 mm
Valve TrainSingle overhead camshaft SOHCSingle overhead camshaft SOHCSingle overhead camshaft SOHCSingle overhead camshaft SOHCSingle overhead camshaft SOHCSingle overhead camshaft SOHCSingle overhead camshaft SOHCSingle overhead camshaft SOHC
Compression Ratio11:1 11:1 11:1 11:1 11:1 11:1 9:1 9:1
Engine block material
Cylinder head material
Fuel Systemefiefiefiefiefiefiefiefi
CoolantWaterWaterWaterWaterWaterWaterWaterWater
Engine Data accuracy
A 150
A 150 Automatic
A 170
A 170 Automatic
A 200
A 200 Automatic
A 200 Turbo
A 200 Turbo Automatic

Car body variants (1)

HAT
Variants#HAT
#HAT
Body styleHatchbackHatchback
no.Doors
Wheelbase2568 mm2568 mm
Lenght3838 mm3838 mm
Width1764 mm1764 mm
Height1593 mm1595 mm
Curb Weight
Wheel Drive
Engine LocationFrontFront
Chassis
Seating capacity (number)
Track Tread (front)1556 mm1552 mm
Track Tread (rear)1551 mm1547 mm
Luggage capacity (min)
Luggage capacity (max)
Weight distribution (FRONT)
Engine AlignmentTransverseTransverse
Drag Coefficient
Equipment
A 150
A 160 CDI
A 170
A 180 CDI
A 150 Automatic
A 160 CDI Automatic
A 170 Automatic
A 180 CDI Automatic
A 200
A 200 CDI
A 200 Turbo
A 200 Automatic
A 200 CDI Automatic
A 200 Turbo Automatic

Linked Cars

Related people

Market Sales

Market Sales info not avaiable.

edit Flag

Assembly site(s)

Sales figures

No sales informations avaiable
