Generation
Isuzu Piazza JR120/130
Produced from 1980 to 1990
Also known as: Isuzu Impulse JR120/130
Generation of Isuzu Piazza
Informations about
Generation of Isuzu Piazza
Produced from 1980 to 1990
Also known as: Isuzu Impulse JR120/130
| Year | Model Name | Fuel | Body | WheelDrive | Pr.From | to | Speed | QOD | |
|---|---|---|---|---|---|---|---|---|---|
| Year | Model Name | Fuel | Body | WheelDrive | Pr.From | to | Speed | QOD | |
| 1985 | Isuzu Piazza XN | Petrol | Coupé | RWD | 180 km/h | 1 | E | ||
| 1985 | Isuzu Piazza XG Automatic | Petrol | Coupé | RWD | - | 1 | E | ||
| 1985 | Isuzu Piazza XG | Petrol | Coupé | RWD | 180 km/h | 1 | E | ||
| 1985 | Isuzu Piazza Turbo XS Automatic | Petrol | Coupé | RWD | 180 km/h | 1 | E | ||
| 1985 | Isuzu Piazza Turbo XS | Petrol | Coupé | RWD | 180 km/h | 1 | E | ||
| 1985 | 1985 Isuzu Piazza Turbo | Petrol | Coupé | RWD | 209 km/h | 1 | E | ||
| 1987 | Isuzu Piazza XL | Petrol | Coupé | RWD | 1987 | 1990 | 185 km/h | 1 | B |
| Id.Engine | 1949 cc | 1949 cc | 1949 cc | 1949 cc | 1949 cc | 1949 cc | 1994 cc |
|---|---|---|---|---|---|---|---|
| Kind of Engine | Naturally aspirated | Naturally aspirated | Naturally aspirated | Naturally aspirated | Turbocharged | Turbocharged | Turbocharged |
| Identificative engine | |||||||
| Cylinders Configuration | Straight/Inline Engine | Straight/Inline Engine | Straight/Inline Engine | Straight/Inline Engine | Straight/Inline Engine | Straight/Inline Engine | Straight/Inline Engine |
| Displacement | 1949 cc | 1949 cc | 1949 cc | 1949 cc | 1949 cc | 1949 cc | 1994 cc |
| Cylinders number | 4 | 4 | 4 | 4 | 4 | 4 | 4 |
| Fuel | Petrol | Petrol | Petrol | Petrol | Petrol | Petrol | Petrol |
| Electric engine - kind | |||||||
| Battery kind | |||||||
| Peak Power (hp) | |||||||
| Peak Power (kW) | |||||||
| Battery power | |||||||
| Operating Voltage | |||||||
| Battery: Operating Temperature | |||||||
| Battery: System Voltage | |||||||
| Battery: Cell Configuration | |||||||
| Battery: 0-80% Charge time | |||||||
| Torque | 145 N-m | 162 N-m | 167 N-m | 167 N-m | 250 N-m | 250 N-m | 225 N-m |
| Torque @ r.p.m. | 3000 rpm | 4000 rpm | 5000 rpm | 5000 rpm | 3400 rpm | 3400 rpm | 3000 rpm |
| Cylinders angle | |||||||
| Maximum Power (HP) | 118 hp | 133 hp | 133 hp | 178 hp | 178 hp | 148 hp | |
| Power (PS) | 102 ps | 120 ps | 135 ps | 135 ps | 180 ps | 180 ps | 150 ps |
| Power kW | 75 kW | 88 kW | 99 kW | 99 kW | 133 kW | 133 kW | 110 kW |
| Power @ rounds per minute | 5400 rpm | 5800 rpm | 6800 rpm | 6800 rpm | 5400 rpm | 5400 rpm | 5400 rpm |
| Bore | 87 mm | 87 mm | 87 mm | 87 mm | 87 mm | 87 mm | 88 mm |
| Stroke | 82 mm | 82 mm | 82 mm | 82 mm | 82 mm | 82 mm | 82 mm |
| Valve Train | Single overhead camshaft SOHC | Single overhead camshaft SOHC | Double overhead camshaft DOHC | Double overhead camshaft DOHC | Double overhead camshaft DOHC | Double overhead camshaft DOHC | Single overhead camshaft SOHC |
| Compression Ratio | 8.8:1 | 8.8:1 | 9:1 | 9:1 | 8.2:1 | 8.2:1 | 7.9:1 |
| Engine block material | Cast Iron | ||||||
| Cylinder head material | Light alloy | ||||||
| Fuel System | efi | efi | efi | efi | efi | efi | |
| Coolant | Water | Water | Water | Water | Water | Water | Water |
| Engine Data accuracy | B | ||||||
| Piazza XL | Piazza XN | Piazza XG | Piazza XG Automatic | Piazza Turbo XS | Piazza Turbo XS Automatic | Piazza Turbo |
| Variants | #COU | #COU |
|---|---|---|
| Body style | Coupé | Coupé |
| no.Doors | ||
| Wheelbase | 2440 mm | 2440 mm |
| Lenght | 4310 mm | 4385 mm |
| Width | 1655 mm | 1675 mm |
| Height | 1300 mm | 1305 mm |
| Curb Weight | ||
| Wheel Drive | ||
| Engine Location | Front | Front |
| Chassis | ||
| Seating capacity (number) | ||
| Track Tread (front) | 1355 mm | 1355 mm |
| Track Tread (rear) | 1345 mm | 1345 mm |
| Luggage capacity (min) | ||
| Luggage capacity (max) | ||
| Weight distribution (FRONT) | ||
| Engine Alignment | Longitudinal | Longitudinal |
| Drag Coefficient | ||
| Equipment | ||
| Piazza XN Piazza XG Automatic Piazza XG Piazza Turbo XS Automatic Piazza Turbo XS Piazza Turbo | Piazza XL |
