Generation of Ford Sierra

Generation

Ford Sierra '82

Produced from 1982 to 1987

Makes » Ford » Ford Sierra » Ford Sierra '82

Informations about

End of production

Trim Levels/Versions

18
YearModel NameFuelBodyWheelDrivePr.FromtoSpeedQOD
YearModel NameFuelBodyWheelDrivePr.FromtoSpeedQOD
1985 Ford Sierra 1.6 GL Petrol HatchbackRWD 180 km/h 1
E
1984 1984 Ford Sierra 2300 GL Diesel Diesel HatchbackRWD 155 km/h 1
E
1984 1984 Ford Sierra 2300 GL Diesel Estate Diesel Station Wagon / EstateRWD - 1
E
1984 1984 Ford Sierra 2.3 GL Automatic Petrol SedanRWD - 1
E
1984 1984 Ford Sierra XR4i Petrol SedanRWD 209 km/h 2
D
1984 1984 Ford Sierra 2.0 Ghia Petrol SedanRWD - 1
E
1984 1984 Ford Sierra 2.0 Petrol SedanRWD - 1
E
1985 Ford Sierra 1.8 Petrol SedanRWD 178 km/h 1
E
1985 Ford Sierra 1.8 Estate Petrol Station Wagon / EstateRWD 175 km/h 1
E
1985 1985 Ford Sierra 2.0iS Petrol SedanRWD - 1
E
1984 1984 Ford Sierra 1.6 Ghia Petrol SedanRWD 166 km/h 1
E
1984 1984 Ford Sierra 1.3 Petrol SedanRWD 152 km/h 1
E
1984 1984 Ford Sierra 1.6 Estate Petrol Station Wagon / EstateRWD - 1
E
1984 1984 Ford Sierra 2300 GL Petrol HatchbackRWD 190 km/h 1
E
1983 Ford Sierra Station Wagon 2.0 V6 Petrol Station Wagon / EstateRWD 173 km/h 1
E
1983 Ford Sierra Station Wagon 2.0 V6 Automatic Petrol Station Wagon / EstateRWD 165 km/h 1
E
1983 Ford Sierra 2.0 V6 Petrol SedanRWD 176 km/h 1
E
1983 Ford Sierra 2.0 V6 Automatic Petrol SedanRWD 168 km/h 1
E

Engines

11
» Diesel Engines
Id.Engine2304 cc
Kind of EngineNaturally aspirated
Identificative engine
Cylinders ConfigurationStraight/Inline Engine
Displacement2304 cc
Cylinders number4
FuelDiesel
Electric engine - kind
Battery kind
Peak Power (hp)
Peak Power (kW)
Battery power
Operating Voltage
Battery: Operating Temperature
Battery: System Voltage
Battery: Cell Configuration
Battery: 0-80% Charge time
Torque139 N-m
Torque @ r.p.m. 2000 rpm
Cylinders angle
Maximum Power (HP)67 hp
Power (PS)68 ps
Power kW50 kW
Power @ rounds per minute4200 rpm
Bore94 mm
Stroke83 mm
Valve TrainOverhead valves OHV
Compression Ratio22.2:1
Engine block material
Cylinder head material
Fuel Systemrotodiesel diesel inj.
CoolantWater
Engine Data accuracy
Sierra 2300 GL Diesel
Sierra 2300 GL Diesel Estate
» Petrol Engines
Id.Engine1294 cc1593 cc1593 cc1598 cc1796 cc1993 cc1993 cc1999 cc2294 cc2792 cc
Kind of EngineNaturally aspiratedNaturally aspiratedNaturally aspiratedNaturally aspiratedNaturally aspiratedNaturally aspiratedNaturally aspiratedNaturally aspiratedNaturally aspiratedNaturally aspirated
Identificative engine
Cylinders ConfigurationStraight/Inline EngineStraight/Inline EngineStraight/Inline EngineStraight/Inline EngineStraight/Inline EngineStraight/Inline EngineStraight/Inline EngineV EngineV EngineV Engine
Displacement1294 cc1593 cc1593 cc1598 cc1796 cc1993 cc1993 cc1999 cc2294 cc2792 cc
Cylinders number4 4 4 4 4 4 4 6 6 6
FuelPetrolPetrolPetrolPetrolPetrolPetrolPetrolPetrolPetrolPetrol
Electric engine - kind
Battery kind
Peak Power (hp)
Peak Power (kW)
Battery power
Operating Voltage
Battery: Operating Temperature
Battery: System Voltage
Battery: Cell Configuration
Battery: 0-80% Charge time
Torque98 N-m119 N-m123 N-m120 N-m140 N-m157 N-m160 N-m150 N-m176 N-m216 N-m
Torque @ r.p.m. 3100 rpm 2900 rpm 2900 rpm 2800 rpm 3500 rpm 4000 rpm 4000 rpm 3000 rpm 3000 rpm 4300 rpm
Cylinders angle60
Maximum Power (HP)60 hp75 hp75 hp79 hp89 hp105 hp115 hp89 hp114 hp160 hp
Power (PS)61 ps76 ps76 ps80 ps90 ps106 ps117 ps90 ps116 ps162 ps
Power kW45 kW56 kW56 kW59 kW66 kW78 kW86 kW66 kW85 kW119 kW
Power @ rounds per minute5700 rpm5300 rpm4900 rpm5500 rpm5400 rpm5200 rpm5500 rpm5000 rpm5300 rpm5700 rpm
Bore79 mm87.65 mm87.65 mm80.98 mm86.2 mm90.8 mm90.8 mm84 mm90 mm93 mm
Stroke66 mm66 mm66 mm77.62 mm76.95 mm76.95 mm76.95 mm60.1 mm60.1 mm68.5 mm
Valve TrainSingle overhead camshaft SOHCSingle overhead camshaft SOHCSingle overhead camshaft SOHCOverhead valves OHVSingle overhead camshaft SOHCSingle overhead camshaft SOHCSingle overhead camshaft SOHCOverhead valves OHVOverhead valves OHVOverhead valves OHV
Compression Ratio9:1 9.2:1 9.5:1 9.2:1 9.5:1 9:1 9.2:1 9:1 9:1 9.2:1
Engine block material
Cylinder head material
Fuel System1 fo carb1 fo carb1 we carb1 carburettor1 we carbbo l-jet fuel inj.1 carburettor1 so carbbo l-jet fuel inj.
CoolantWaterWaterWaterWaterWaterWaterWaterWaterWaterother
Engine Data accuracy
D
Sierra 1.3
Sierra 1.6 Estate
Sierra 1.6 Ghia
Sierra 1.6 GL
Sierra 1.8
Sierra 1.8 Estate
Sierra 2.0 Ghia
Sierra 2.0
Sierra 2.0iS
Sierra Station Wagon 2.0 V6
Sierra Station Wagon 2.0 V6 Automatic
Sierra 2.0 V6
Sierra 2.0 V6 Automatic
Sierra 2.3 GL Automatic
Sierra 2300 GL
Sierra XR4i

Car body variants

3 HAT SED SWG
Variants#HAT
#HAT
#SED
#SED
#SED
#SED
#SED
#SED
#SED
#SED
#SWG
#SWG
#SWG
#SWG
Body styleHatchbackHatchbackSedanSedanSedanSedanSedanSedanSedanSedanStation Wagon / EstateStation Wagon / EstateStation Wagon / EstateStation Wagon / Estate
no.Doors
Wheelbase2608 mm2610 mm2608 mm2610 mm2608 mm2608 mm2608 mm2608 mm2608 mm2608 mm2608 mm2610 mm2608 mm2610 mm
Lenght4408 mm4410 mm4390 mm4390 mm4390 mm4410 mm4420 mm4425 mm4425 mm4425 mm4490 mm4490 mm4490 mm4500 mm
Width1720 mm1720 mm1700 mm1670 mm1670 mm1720 mm1720 mm1725 mm1725 mm1725 mm1710 mm1670 mm1670 mm1730 mm
Height1362 mm1410 mm1410 mm1360 mm1360 mm1410 mm1410 mm1360 mm1360 mm1360 mm1440 mm1390 mm1390 mm1440 mm
Curb Weight
Wheel Drive
Engine LocationFrontFrontFrontFrontFrontFrontFrontFrontFrontFrontFrontFrontFrontFront
Chassis
Seating capacity (number)
Track Tread (front)1451 mm1450 mm1450 mm1450 mm1450 mm1450 mm1450 mm1452 mm1450 mm1450 mm1450 mm1450 mm1450 mm
Track Tread (rear)1468 mm1470 mm1470 mm1470 mm1470 mm1470 mm1470 mm1468 mm1470 mm1470 mm1460 mm1460 mm1470 mm
Luggage capacity (min)
Luggage capacity (max)
Weight distribution (FRONT)
Engine AlignmentLongitudinalLongitudinalLongitudinalLongitudinalLongitudinalLongitudinalLongitudinalLongitudinalLongitudinalLongitudinalLongitudinalLongitudinalLongitudinalLongitudinal
Drag Coefficient
Equipment
Sierra 1.6 GL
Sierra 2300 GL Diesel
Sierra 2300 GL
Sierra 1.3
Sierra 2.0 V6
Sierra 2.0 V6 Automatic
Sierra 1.8
Sierra 2.3 GL Automatic
Sierra 2.0
Sierra 2.0 Ghia
Sierra 2.0iS
Sierra 1.6 Ghia
Sierra XR4i
Sierra 1.6 Estate
Sierra Station Wagon 2.0 V6
Sierra Station Wagon 2.0 V6 Automatic
Sierra 1.8 Estate
Sierra 2300 GL Diesel Estate
