Generation of Ford Fiesta

Generation

Ford Fiesta MKV

Produced from 2002 to 2005

Makes » Ford » Ford Fiesta » Ford Fiesta MKV

Informations about

Still in production

Trim Levels/Versions

5
YearModel NameFuelBodyWheelDrivePr.FromtoSpeedQOD
YearModel NameFuelBodyWheelDrivePr.FromtoSpeedQOD
2001 2001 Ford Fiesta 1.3 Petrol HatchbackUNK 150 km/h 1
E
2001 2001 Ford Fiesta 1.4 16v Petrol HatchbackUNK 166 km/h 1
E
2001 2001 Ford Fiesta 1.6 16v Petrol HatchbackUNK 185 km/h 1
E
2001 2001 Ford Fiesta TDCi Diesel HatchbackUNK 164 km/h 1
E
2003 Ford Fiesta 1.3 (2003) Petrol HatchbackFWD - 1
E

Engines

5
» Diesel Engines
Id.Engine1399 cc
Kind of EngineTurbocharged
Identificative engine
Cylinders ConfigurationStraight/Inline Engine
Displacement1399 cc
Cylinders number4
FuelDiesel
Electric engine - kind
Battery kind
Peak Power (hp)
Peak Power (kW)
Battery power
Operating Voltage
Battery: Operating Temperature
Battery: System Voltage
Battery: Cell Configuration
Battery: 0-80% Charge time
Torque160 N-m
Torque @ r.p.m. 1750 rpm
Cylinders angle
Maximum Power (HP)67 hp
Power (PS)68 ps
Power kW50 kW
Power @ rounds per minute4000 rpm
Bore73.7 mm
Stroke82 mm
Valve TrainSingle overhead camshaft SOHC
Compression Ratio18:1
Engine block material
Cylinder head material
Fuel System
CoolantWater
Engine Data accuracy
Fiesta TDCi
» Petrol Engines
Id.Engine1295 cc1297 cc1388 cc1596 cc
Kind of EngineNaturally aspiratedNaturally aspiratedNaturally aspirated
Identificative engine
Cylinders ConfigurationStraight/Inline EngineStraight/Inline EngineStraight/Inline EngineStraight/Inline Engine
Displacement1295 cc1297 cc1388 cc1596 cc
Cylinders number4 4 4 4
FuelPetrolPetrolPetrolPetrol
Electric engine - kind
Battery kind
Peak Power (hp)
Peak Power (kW)
Battery power
Operating Voltage
Battery: Operating Temperature
Battery: System Voltage
Battery: Cell Configuration
Battery: 0-80% Charge time
Torque108 N-m101 N-m127 N-m143 N-m
Torque @ r.p.m.2800 rpm 2500 rpm 3500 rpm 4000 rpm
Cylinders angle
Maximum Power (HP)57 hp78 hp99 hp
Power (PS)68 ps58 ps79 ps100 ps
Power kW43 kW58 kW74 kW
Power @ rounds per minute5000 rpm5700 rpm6000 rpm
Bore74 mm73.96 mm76 mm79 mm
Stroke76 mm75.48 mm76.5 mm81.4 mm
Valve TrainSingle overhead camshaft SOHCDouble overhead camshaft DOHCDouble overhead camshaft DOHC
Compression Ratio10.2:1 11:1 11:1
Engine block material
Cylinder head material
Fuel Systemefiefiefi
CoolantWaterWaterWater
Engine Data accuracy
Fiesta 1.3
Fiesta 1.3
Fiesta 1.4 16v
Fiesta 1.6 16v

Car body variants

1 HAT
Variants#HAT
#HAT
Body styleHatchbackHatchback
no.Doors
Wheelbase2487 mm2490 mm
Lenght3917 mm3920 mm
Width1683 mm1690 mm
Height1417 mm1420 mm
Curb Weight
Wheel Drive
Engine LocationFrontFront
Chassis
Seating capacity (number)
Track Tread (front)1477 mm
Track Tread (rear)1444 mm
Luggage capacity (min)
Luggage capacity (max)
Weight distribution (FRONT)
Engine AlignmentTransverse
Drag Coefficient
Equipment
Fiesta 1.3
Fiesta 1.4 16v
Fiesta 1.6 16v
Fiesta TDCi
Fiesta 1.3
