Fiat Coupé

Trim Levels/Versions

Year	Model Name	Fuel	Body	WheelDrive	Pr.From	to	Speed		QOD
Year	Model Name	Fuel	Body	WheelDrive	Pr.From	to	Speed		QOD
1996	Fiat Coupé 1.8 16v (1996)	Petrol	Coupé	FWD	1996	2000	205 km/h	1	D
1994	Fiat Coupé 2.0 16v Turbo 190HP (1994)	Petrol	Coupé	FWD	1994	1997	230 km/h	1	E
1994	Fiat Coupé 2.0 16v (1994)	Petrol	Coupé	FWD	1993	1997	208 km/h	1	E
1998	Fiat Coupé 2.0 20v Turbo 220HP Limited Edition (1996)	Petrol	Coupé	FWD	1998	1999	250 km/h	2	D
1996	Fiat Coupé 2.0 20v 150HP (1996)	Petrol	Coupé	FWD	1996	1999	212 km/h	1	E
1996	Fiat Coupé 2.0 20v Turbo 220HP (1996)	Petrol	Coupé	FWD	1996	1999	250 km/h	1	E
1999	Fiat Coupé 2.0 20v 155HP (1996)	Petrol	Coupé	FWD	1999	2000	215 km/h	1	E

Engines

» Petrol Engines

Id.Engine	1747 cc	1995 cc	1995 cc	1998 cc	1998 cc	1998 cc
Kind of Engine	Naturally aspirated	Turbocharged	Naturally aspirated	Naturally aspirated	Naturally aspirated	Turbocharged
Identificative engine	1.8 Pratola Serra	2.0 Lampredi Turbo 16V 190	2.0 Pratola Serra	2.0 Pratola Serra 20v 150HP	2.0 Pratola Serra 20v 150HP	2.0 Pratola Serra Turbo 20V 220
Cylinders Configuration	Straight/Inline Engine	Straight/Inline Engine	Straight/Inline Engine	Straight/Inline Engine	Straight/Inline Engine	Straight/Inline Engine
Displacement	1747 cc	1995 cc	1995 cc	1998 cc	1998 cc	1998 cc
Cylinders number	4	4	4	5	5	5
Fuel	Petrol	Petrol	Petrol	Petrol	Petrol	Petrol
Electric engine - kind
Battery kind
Peak Power (hp)
Peak Power (kW)
Battery power
Operating Voltage
Battery: Operating Temperature
Battery: System Voltage
Battery: Cell Configuration
Battery: 0-80% Charge time
Torque	164 N-m	290 N-m	180 N-m	186 N-m	186 N-m	310 N-m
Torque @ r.p.m.	4300 rpm			4500 rpm	4500 rpm	2500 rpm
Cylinders angle
Maximum Power (HP)	130 hp	190 hp	139 hp	148 hp	154 hp	216 hp
Power (PS)	132 ps		142 ps	150 ps	155 ps	219 ps
Power kW	97 kW	140 kW	102 kW	110 kW	113 kW	161 kW
Power @ rounds per minute	6300 rpm	5500 rpm	6000 rpm	6100 rpm	6500 rpm	5750 rpm
Bore	82 mm		84 mm	82 mm	82 mm	82 mm
Stroke	82.7 mm		90 mm	75.65 mm	75.65 mm	75.65 mm
Valve Train	Double overhead camshaft DOHC	Double overhead camshaft DOHC	Double overhead camshaft DOHC	Double overhead camshaft DOHC	Double overhead camshaft DOHC	Double overhead camshaft DOHC
Compression Ratio	10.3:1			10:1	10:1	8.5:1
Engine block material
Cylinder head material
Fuel System	mpfi	bo fuel inj.		mpfi	mpfi	mpfi
Coolant	Water	Water	Water	Water	Water	Water
Engine Data accuracy	C	E	E	C	C
	Coupé 1.8 16v	Coupé 2.0 16v Turbo 190HP	Coupé 2.0 16v	Coupé 2.0 20v 150HP	Coupé 2.0 20v 155HP	Coupé 2.0 20v Turbo 220HP Limited Edition Coupé 2.0 20v Turbo 220HP

Car body variants

1 COU

Variants	#COU
Body style	Coupé
no.Doors
Wheelbase	2540 mm
Lenght	4250 mm
Width	1768 mm
Height	1340 mm
Curb Weight
Wheel Drive
Engine Location	Front
Chassis
Seating capacity (number)
Track Tread (front)	1483 mm
Track Tread (rear)	1468 mm
Luggage capacity (min)
Luggage capacity (max)
Weight distribution (FRONT)
Engine Alignment	Transverse
Drag Coefficient
Equipment
	Coupé 1.8 16v Coupé 2.0 16v Turbo 190HP Coupé 2.0 16v Coupé 2.0 20v Turbo 220HP Limited Edition Coupé 2.0 20v 150HP Coupé 2.0 20v Turbo 220HP Coupé 2.0 20v 155HP
