Generation of Fiat 500 Topolino

Generation

Fiat 500 C

Produced from 1949 to 1955

Makes » Fiat » Fiat 500 Topolino » Fiat 500 C

Informations about

End of production

Trim Levels/Versions

3
YearModel NameFuelBodyWheelDrivePr.FromtoSpeedQOD
YearModel NameFuelBodyWheelDrivePr.FromtoSpeedQOD
1949 Fiat 500 C Convertible Petrol Convertible/Cabrio/CabrioletUNK 97 km/h 1
E
1953 Fiat 500 C Petrol SedanUNK 92 km/h 1
E
1953 Fiat 500 C Giardiniera Belvedere Petrol Station Wagon / EstateUNK - 1
E

Engines

2
» Petrol Engines
Id.Engine569 cc569 cc
Kind of EngineNaturally aspiratedNaturally aspirated
Identificative engine500 c
Cylinders ConfigurationStraight/Inline EngineStraight/Inline Engine
Displacement569 cc569 cc
Cylinders number4 4
FuelPetrolPetrol
Electric engine - kind
Battery kind
Peak Power (hp)
Peak Power (kW)
Battery power
Operating Voltage
Battery: Operating Temperature
Battery: System Voltage
Battery: Cell Configuration
Battery: 0-80% Charge time
Torque29 N-m30 N-m
Torque @ r.p.m. 2900 rpm 2900 rpm
Cylinders angle
Maximum Power (HP)16.3 hp16.5 hp
Power (PS)16.5 ps16.7 ps
Power kW12.2 kW12.3 kW
Power @ rounds per minute4400 rpm4400 rpm
Bore52 mm52 mm
Stroke67 mm67 mm
Valve TrainOverhead valves OHVOverhead valves OHV
Compression Ratio6.45:1 6.45:1
Engine block material
Cylinder head material
Fuel System1 weber 22 drs carburettor1 we carb
CoolantWaterother
Engine Data accuracy
500 C
500 C Giardiniera Belvedere
500 C Convertible

Car body variants

3 CVT SED SWG
Variants#CVT
#SED
#SWG
Body styleConvertible/Cabrio/CabrioletSedanStation Wagon / Estate
no.Doors
Wheelbase2000 mm2000 mm2000 mm
Lenght3245 mm3245 mm3320 mm
Width1288 mm1290 mm1290 mm
Height1375 mm1375 mm1410 mm
Curb Weight
Wheel Drive
Engine LocationRearFrontFront
Chassis
Seating capacity (number)
Track Tread (front)1116 mm1116 mm1116 mm
Track Tread (rear)1083 mm1083 mm1083 mm
Luggage capacity (min)
Luggage capacity (max)
Weight distribution (FRONT)
Engine AlignmentLongitudinalLongitudinalLongitudinal
Drag Coefficient
Equipment
500 C Convertible
500 C
500 C Giardiniera Belvedere

Linked Cars

Related people

Market Sales

Market Sales info not avaiable.

edit Flag

Assembly site(s)

Sales figures

No sales informations avaiable
