Restyling of Citroën C3

Mid Generational Restyling, Model year

Citroën C3 II Restyling

Produced from 2013 to 2016

Makes » Citroën » Citroën C3 » Citroën C3 II Restyling

Informations about

Still in production

Trim Levels/Versions

10
YearModel NameFuelBodyWheelDrivePr.FromtoSpeedQOD
YearModel NameFuelBodyWheelDrivePr.FromtoSpeedQOD
2013 Citroën C3 1.0 Petrol HatchbackFWD - 1
E
2013 Citroën C3 1.2 Petrol HatchbackFWD - 1
E
2013 Citroën C3 1.2 e-VTi Petrol HatchbackFWD - 1
E
2013 Citroën C3 1.6 VTi Petrol HatchbackFWD - 1
E
2013 Citroën C3 1.6 VTi Automatic Petrol HatchbackFWD - 1
E
2013 Citroën C3 e-HDi 115 Diesel HatchbackFWD - 1
E
2013 Citroën C3 e-HDi 70 EGS Diesel HatchbackFWD - 1
E
2013 Citroën C3 e-HDi 90 Diesel HatchbackFWD - 1
E
2013 Citroën C3 e-HDi 90 ETG6 Diesel HatchbackFWD - 1
E
2013 Citroën C3 HDi 70 Diesel HatchbackFWD - 1
E

Engines

6
» Diesel Engines
Id.Engine1398 cc1560 cc1560 cc
Kind of EngineTurbochargedTurbochargedTurbocharged
Identificative engine
Cylinders ConfigurationStraight/Inline EngineStraight/Inline EngineStraight/Inline Engine
Displacement1398 cc1560 cc1560 cc
Cylinders number4 4 4
FuelDieselDieselDiesel
Electric engine - kind
Battery kind
Peak Power (hp)
Peak Power (kW)
Battery power
Operating Voltage
Battery: Operating Temperature
Battery: System Voltage
Battery: Cell Configuration
Battery: 0-80% Charge time
Torque160 N-m230 N-m270 N-m
Torque @ r.p.m. 1750 rpm 1750 rpm 1750 rpm
Cylinders angle
Maximum Power (HP)67 hp91 hp112 hp
Power (PS)68 ps92 ps114 ps
Power kW50 kW68 kW84 kW
Power @ rounds per minute4000 rpm4000 rpm3600 rpm
Bore73.7 mm75 mm75 mm
Stroke82 mm88.3 mm88.3 mm
Valve TrainDouble overhead camshaft DOHCDouble overhead camshaft DOHCDouble overhead camshaft DOHC
Compression Ratio
Engine block material
Cylinder head material
Fuel Systemcommon rail direct diesel injectioncommon rail direct diesel injectioncommon rail direct diesel injection
CoolantWaterWaterWater
Engine Data accuracy
D
D
C3 e-HDi 70 EGS
C3 HDi 70
C3 e-HDi 90
C3 e-HDi 90 ETG6
C3 e-HDi 115
» Petrol Engines
Id.Engine999 cc1598 cc1999 cc
Kind of EngineNaturally aspiratedTurbochargedNaturally aspirated
Identificative engine
Cylinders ConfigurationStraight/Inline EngineStraight/Inline EngineStraight/Inline Engine
Displacement999 cc1598 cc1999 cc
Cylinders number3 4 3
FuelPetrolPetrolPetrol
Electric engine - kind
Battery kind
Peak Power (hp)
Peak Power (kW)
Battery power
Operating Voltage
Battery: Operating Temperature
Battery: System Voltage
Battery: Cell Configuration
Battery: 0-80% Charge time
Torque95 N-m160 N-m118 N-m
Torque @ r.p.m. 3000 rpm 4250 rpm 2750 rpm
Cylinders angle
Maximum Power (HP)67 hp118 hp81 hp
Power (PS)68 ps120 ps82 ps
Power kW50 kW88 kW60 kW
Power @ rounds per minute6000 rpm6000 rpm5750 rpm
Bore71 mm77 mm75 mm
Stroke84.1 mm85.8 mm90.5 mm
Valve TrainDouble overhead camshaft DOHCDouble overhead camshaft DOHCDouble overhead camshaft DOHC
Compression Ratio
Engine block material
Cylinder head material
Fuel Systemefiefiefi
CoolantWaterWaterWater
Engine Data accuracy
D
D
C3 1.0
C3 1.6 VTi
C3 1.6 VTi Automatic
C3 1.2
C3 1.2 e-VTi

Car body variants

1 HAT
Variants#HAT
Body styleHatchback
no.Doors
Wheelbase2466 mm
Lenght3941 mm
Width1728 mm
Height1524 mm
Curb Weight
Wheel Drive
Engine LocationFront
Chassis
Seating capacity (number)
Track Tread (front)
Track Tread (rear)
Luggage capacity (min)
Luggage capacity (max)
Weight distribution (FRONT)
Engine AlignmentTransverse
Drag Coefficient
Equipment
C3 1.0
C3 1.2
C3 1.2 e-VTi
C3 1.6 VTi
C3 1.6 VTi Automatic
C3 e-HDi 115
C3 e-HDi 70 EGS
C3 e-HDi 90
C3 e-HDi 90 ETG6
C3 HDi 70
