Generation of Citroën AX

Generation

Citroën AX I Serie

Produced from 1986 to 1990

Makes » Citroën » Citroën AX » Citroën AX I Serie

Informations about

End of production

Trim Levels/Versions

6
YearModel NameFuelBodyWheelDrivePr.FromtoSpeedQOD
YearModel NameFuelBodyWheelDrivePr.FromtoSpeedQOD
1987 1987 Citroën AX 10 E Petrol HatchbackFWD 145 km/h 1
1987 1987 Citroën AX 4X4 Petrol HatchbackFWD 167 km/h 1
1987 1987 Citroën AX GT Petrol HatchbackFWD 177 km/h 1
1987 1987 Citroën AX Sport Petrol HatchbackFWD 177 km/h 1
1987 1987 Citroën AX 11 Petrol HatchbackFWD - 1
1989 1989 Citroën AX 14RD Diesel HatchbackFWD 146 km/h 1

Engines

6
» Diesel Engines
Id.Engine1360 cc
Kind of EngineNaturally aspirated
Identificative engine
Cylinders ConfigurationStraight/Inline Engine
Displacement1360 cc
Cylinders number4
FuelDiesel
Electric engine - kind
Battery kind
Peak Power (hp)
Peak Power (kW)
Battery power
Operating Voltage
Battery: Operating Temperature
Battery: System Voltage
Battery: Cell Configuration
Battery: 0-80% Charge time
Torque86 N-m
Torque @ r.p.m. 2500 rpm
Cylinders angle
Maximum Power (HP)52 hp
Power (PS)53 ps
Power kW39 kW
Power @ rounds per minute5000 rpm
Bore75 mm
Stroke77 mm
Valve TrainSingle overhead camshaft SOHC
Compression Ratio22:1
Engine block material
Cylinder head material
Fuel System
CoolantWater
Engine Data accuracy
AX 14RD
» Petrol Engines
Id.Engine954 cc1124 cc1294 cc1360 cc1360 cc
Kind of EngineNaturally aspiratedNaturally aspiratedNaturally aspiratedNaturally aspiratedNaturally aspirated
Identificative enginetu9
Cylinders ConfigurationStraight/Inline EngineStraight/Inline EngineStraight/Inline EngineStraight/Inline EngineStraight/Inline Engine
Displacement954 cc1124 cc1294 cc1360 cc1360 cc
Cylinders number4 4 4 4 4
FuelPetrolPetrolPetrolPetrolPetrol
Electric engine - kind
Battery kind
Peak Power (hp)
Peak Power (kW)
Battery power
Operating Voltage
Battery: Operating Temperature
Battery: System Voltage
Battery: Cell Configuration
Battery: 0-80% Charge time
Torque71 N-m112 N-m115 N-m116 N-m
Torque @ r.p.m. 2400 rpm 5000 rpm 4000 rpm
Cylinders angle
Maximum Power (HP)44 hp55 hp95 hp75 hp85 hp
Power (PS)44.6 ps56 ps96 ps76 ps86 ps
Power kW32.8 kW41 kW71 kW56 kW63 kW
Power @ rounds per minute5200 rpm5800 rpm6800 rpm5800 rpm6400 rpm
Bore70 mm72 mm75 mm75 mm75 mm
Stroke62 mm69 mm73.2 mm77 mm77 mm
Valve TrainSingle overhead camshaft SOHCSingle overhead camshaft SOHCSingle overhead camshaft SOHCSingle overhead camshaft SOHCSingle overhead camshaft SOHC
Compression Ratio9.4:1 9.6:1 9.3:1
Engine block material
Cylinder head material
Fuel System1 weber 32 isbh 16 carburettor2 so carbs1 so carb
CoolantWaterWaterWaterWater
Engine Data accuracy
D
AX 10 E
AX 11
AX Sport
AX 4X4
AX GT

Car body variants

1 HAT
Variants#HAT
#HAT
#HAT
#HAT
Body styleHatchbackHatchbackHatchbackHatchback
no.Doors
Wheelbase2286 mm2285 mm2286 mm2286 mm
Lenght3531 mm3531 mm3531 mm3531 mm
Width1575 mm1575 mm1575 mm1600 mm
Height1346 mm1346 mm1346 mm1340 mm
Curb Weight
Wheel Drive
Engine LocationFrontFrontFront
Chassis
Seating capacity (number)
Track Tread (front)1397 mm
Track Tread (rear)1321 mm
Luggage capacity (min)
Luggage capacity (max)
Weight distribution (FRONT)
Engine AlignmentTransverseTransverseTransverse
Drag Coefficient
Equipment
AX 4X4
AX 14RD
AX 10 E
AX 11
AX GT
AX Sport

Linked Cars

Related people

Market Sales

Market Sales info not avaiable.

edit Flag

Assembly site(s)

Sales figures

No sales informations avaiable
