Generation of Alfa Romeo 166

Generation

Alfa Romeo 166 Restyling

Produced from 2003 to 2007

Makes » Alfa Romeo » Alfa Romeo 166 » Alfa Romeo 166 Restyling

Informations about

End of production

Trim Levels/Versions

8
YearModel NameFuelBodyWheelDrivePr.FromtoSpeedQOD
YearModel NameFuelBodyWheelDrivePr.FromtoSpeedQOD
2003 2003 Alfa Romeo 166 2.4 JTD 20v Diesel Sedan - 1
E
2003 2003 Alfa Romeo 166 2.5 V6 24v Petrol Sedan - 1
E
2003 2003 Alfa Romeo 166 3.0 V6 24v CAE Petrol Sedan - 1
E
2003 2003 Alfa Romeo 166 3.2 V6 24v Petrol Sedan - 1
E
2003 2003 Alfa Romeo 166 TS Petrol Sedan - 1
E
2003 2003 Alfa Romeo 166 2.4 JTD 20v CAE Diesel Sedan - 1
E
2003 2003 Alfa Romeo 166 2.4 JTD Diesel Sedan - 1
E
2007 Alfa Romeo 166 JTD M-JET 20V Diesel Sedan - 1
E

Engines

8
» Diesel Engines
Id.Engine2387 cc2387 cc2387 cc2387 cc
Kind of EngineTurbochargedTurbochargedTurbochargedTurbocharged
Identificative engine
Cylinders ConfigurationStraight/Inline EngineStraight/Inline EngineStraight/Inline EngineStraight/Inline Engine
Displacement2387 cc2387 cc2387 cc2387 cc
Cylinders number5 5 5 5
FuelDieselDieselDieselDiesel
Electric engine - kind
Battery kind
Peak Power (hp)
Peak Power (kW)
Battery power
Operating Voltage
Battery: Operating Temperature
Battery: System Voltage
Battery: Cell Configuration
Battery: 0-80% Charge time
Torque305 N-m385 N-m330 N-m385 N-m
Torque @ r.p.m. 1800 rpm 2000 rpm 1750 rpm 2000 rpm
Cylinders angle
Maximum Power (HP)148 hp172 hp172 hp182 hp
Power (PS)150 ps174 ps174 ps185 ps
Power kW110 kW128 kW128 kW136 kW
Power @ rounds per minute4000 rpm4000 rpm4000 rpm4000 rpm
Bore82 mm82 mm82 mm82 mm
Stroke90.4 mm90.4 mm90.4 mm90.4 mm
Valve TrainSingle overhead camshaft SOHCDouble overhead camshaft DOHCDouble overhead camshaft DOHCDouble overhead camshaft DOHC
Compression Ratio18.45:1 18:1 18:1 18.1:1
Engine block material
Cylinder head material
Fuel Systemdirect diesel inj.direct diesel inj.direct diesel inj.common rail direct diesel injection
CoolantWaterWaterWaterWater
Engine Data accuracy
166 2.4 JTD
166 2.4 JTD 20v
166 2.4 JTD 20v CAE
166 JTD M-JET 20V
» Petrol Engines
Id.Engine1970 cc2492 cc2959 cc3179 cc
Kind of EngineNaturally aspiratedNaturally aspiratedNaturally aspiratedNaturally aspirated
Identificative engine
Cylinders ConfigurationStraight/Inline EngineV EngineV EngineV Engine
Displacement1970 cc2492 cc2959 cc3179 cc
Cylinders number4 6 6 6
FuelPetrolPetrolPetrolPetrol
Electric engine - kind
Battery kind
Peak Power (hp)
Peak Power (kW)
Battery power
Operating Voltage
Battery: Operating Temperature
Battery: System Voltage
Battery: Cell Configuration
Battery: 0-80% Charge time
Torque181 N-m221 N-m265 N-m289 N-m
Torque @ r.p.m. 3800 rpm 5000 rpm 5000 rpm 4800 rpm
Cylinders angle60 60 60
Maximum Power (HP)148 hp185 hp217 hp237 hp
Power (PS)150 ps188 ps220 ps240 ps
Power kW110 kW138 kW162 kW177 kW
Power @ rounds per minute6300 rpm6300 rpm6300 rpm6200 rpm
Bore83 mm88 mm93 mm93 mm
Stroke91 mm68.3 mm72.6 mm78 mm
Valve TrainDouble overhead camshaft DOHCDouble overhead camshaft DOHCDouble overhead camshaft DOHCDouble overhead camshaft DOHC
Compression Ratio10:1 10.3:1 10:1 10.5:1
Engine block material
Cylinder head material
Fuel Systembo motronic m1.5.5 fuel inj.bo motronic m2.1 fuel inj.bo motronic me2.1 fuel inj.bo motronic me7 fuel inj.
CoolantWaterWaterWaterWater
Engine Data accuracy
166 TS
166 2.5 V6 24v
166 3.0 V6 24v CAE
166 3.2 V6 24v

Car body variants

1 SED
Variants#SED
Body styleSedan
no.Doors
Wheelbase2700 mm
Lenght4720 mm
Width1800 mm
Height1416 mm
Curb Weight
Wheel Drive
Engine LocationFront
Chassis
Seating capacity (number)
Track Tread (front)1554 mm
Track Tread (rear)1542 mm
Luggage capacity (min)
Luggage capacity (max)
Weight distribution (FRONT)
Engine AlignmentTransverse
Drag Coefficient
Equipment
166 2.4 JTD 20v
166 2.5 V6 24v
166 3.0 V6 24v CAE
166 3.2 V6 24v
166 TS
166 2.4 JTD 20v CAE
166 2.4 JTD
166 JTD M-JET 20V

Linked Cars

Related people

Market Sales

Market Sales info not avaiable.

edit Flag

Assembly site(s)

Sales figures

No sales informations avaiable
